PT06A-16-26P Compatible 26-Pin Bayonet Straight Plug
High-density shell size 16 miniature plug with 26 pin solder contacts, three-point bayonet coupling and service class A shell.
Product Number TC-PT06A-16-26P
PT06A-16-26P compatible high-density bayonet straight plug with 26 pin solder contacts for multi-circuit cable assemblies.
- 26-contact high-density layout
- Quick bayonet mating
- PT06A-16-26P cross-reference
- Complete mating-set quotation
Product Description
PT06A-16-26P is a cross-reference for a high-density miniature circular straight plug in the PT and MIL-DTL-26482 Series I interface family. The configuration identifies shell size 16, insert arrangement 26, twenty-six pin solder contacts and service class A. It is suited to control, instrumentation and signal harnesses that require many circuits in a compact bayonet-coupled connector. This listing is for a compatible alternative. Confirm pin numbering, mating receptacle, solder-cup dimensions, finish, cable diameter and backshell requirement before quotation. A complete plug-and-receptacle set can be supplied with cable clamps and protective accessories.
Use PT-series or MIL-DTL-26482 Series I compatible wording unless the quoted manufacturer provides applicable qualification evidence. Final insert orientation and dimensions follow the approved supplier drawing.
Technical Specifications
Technical parameters are confirmed from the complete part number, drawing or application requirement before quotation.
